NTD4913N
Power MOSFET
30 V, 32 A, Single N ? Channel, DPAK/IPAK
Features
? Low R DS(on) to Minimize Conduction Losses
? Low Capacitance to Minimize Driver Losses
? Optimized Gate Charge to Minimize Switching Losses
? These are Pb ? Free Devices
Applications
? CPU Power Delivery
? DC ? DC Converters
V (BR)DSS
30 V
http://onsemi.com
R DS(ON) MAX
10.5 m W @ 10 V
15 m W @ 4.5 V
I D MAX
32 A
D
MAXIMUM RATINGS (T J = 25 ° C unless otherwise stated)
Parameter
Symbol
Value
Unit
Drain ? to ? Source Voltage
Gate ? to ? Source Voltage
V DSS
V GS
30
± 20
V
V
G
2 3
3
3
Continuous Drain
Current R q JA
(Note 1)
Power Dissipation
R q JA (Note 1)
Continuous Drain
Current R q JA
(Note 2)
Power Dissipation
R q JA (Note 2)
Continuous Drain
Current R q JC
(Note 1)
Power Dissipation
R q JC (Note 1)
Pulsed Drain
Current
Steady
State
t p =10 m s
T A = 25 ° C
T A = 100 ° C
T A = 25 ° C
T A = 25 ° C
T A = 100 ° C
T A = 25 ° C
T C = 25 ° C
T C = 100 ° C
T C = 25 ° C
T A = 25 ° C
I D
P D
I D
P D
I D
P D
I DM
10.5
7.4
2.5
7.7
5.4
1.36
32
23
24
132
A
W
A
W
A
W
A
1 2 1
STYLE 2 DPAK)
S
N ? CHANNEL MOSFET
4 4
4
1
2
CASE 369AA CASE 369AC CASE 369D
DPAK 3 IPAK IPAK
(Bent Lead) (Straight Lead) (Straight Lead
MARKING DIAGRAMS
Current Limited by Package
T A = 25 ° C
I DmaxPkg
60
A
& PIN ASSIGNMENTS
Operating Junction and Storage
Temperature
Source Current (Body Diode)
T J ,
T STG
I S
? 55 to
+175
20
° C
A
4
Drain
4
Drain
4
Drain
Drain to Source dV/dt
Single Pulse Drain ? to ? Source Avalanche
Energy (T J = 25 ° C, V DD = 50 V, V GS = 10 V,
I L = 21 A pk , L = 0.1 mH, R G = 25 W)
dV/dt
EAS
8.0
22
V/ns
mJ
1
2
3
Source Gate Drain Source
1
2
3
Lead Temperature for Soldering Purposes T L 260 ° C
(1/8” from case for 10 s)
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
1. Surface ? mounted on FR4 board using 1 sq ? in pad, 1 oz Cu.
2. Surface ? mounted on FR4 board using the minimum recommended pad size.
2
1 Drain 3
Gate
Y = Year
WW = Work Week
4913N = Device Code
Gate Drain Source
G
= Pb ? Free Package
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 3 of this data sheet.
? Semiconductor Components Industries, LLC, 2010
June, 2010 ? Rev. 1
1
Publication Order Number:
NTD4913N/D
